LIGHTWEIGHT AND COMPACT
The Horizon 3000 is the lightest and the most compact model in the Horizon range but still offers high spraying outputs with exceptional build quality and reliability.
The 3000 models benefit from having our unique Panoramic cab. Designed in house and built in Germany this cab features the latest Category 4 filtration.
Comfort, visibility, build quality and ergonomics are to the highest standard and the impressive low noise levels take operator wellbeing to the next stage.
ENGINE: Tier 5 Final watercooled engine with Add Blue 140kw/188hp
TRANSMISSION: Fully hydrostatic 4-wheel drive with 4-speed transmission for high field torque and high road speed. Poclain wheel motors
BRAKING: Primary hydrostatic with dynamic braking with foot pedal and boosted braking on the joystick
HYDRAULIC OIL TANK: 200 litres (High Grade HV 46)
STEERING: Selectable 4-wheel steer on foot pedal with auto alignment
CHASSIS: Welded hollow steel section
AXELS: 68” – 80”, 72” – 84” (Mechanical) | Or 68” – 84” Full Hydraulic Sliding.
SUSPENSION: Self levelling hydro-pneumatic | Optional ‘Dual Ride’ facility for softer ride in the field
CAB: High visibility, luxury cab with climate control, high back air seat, CD player, electric mirrors, carbon filtration
IN-CAB CONTROLS: Steering column adjustable for height and angle. Joystick control for forward/reverse, main on/off and control of boom sections and height, and selectable 4-wheel steer. In cab control of clean water rinse tank (with standard pump only)
SPRAY TANK SIZE: 3000 litres
WASH TANK: 300 litres (external) mounted over rear axle
PUMP: Standard 6 cylinder 280l/min | Optional cylinder 400l/min
FILTRATION: Main suction filter with flushing pressure filter and nozzle filters
BOOM SIZE: Standard 24m 2 stage gullwing | Optional VG Boom
SPRAYLINE: Standard stainless steel 0.75in with Prime and Purge boom re-circulation. Triplet nozzle bodies c/w 3 sets of spray tips (customer choice) | Optional Quad, Quin or Twin Lines (Hypro Duo-React)
SECTION CONTROLS: Standard 7 sections
PLUMBING: Twin rotary valves to control self-filling, spray, wash and pump out. Stainless steel 25 litre chemical induction hopper
MIN SPRAY HEIGHT: 0.6m
MAX SPRAY HEIGHT: 2.4m
APPLICATION CONTROL: All GPS makes can be fitted, including Boom Levelling and PWM Systems
DIMENSIONS & WEIGHTS
TURNING CIRCLE: 6m
GROUND CLEARANCE: 950mm
TYRES: Standard 14.9/30 | Optional 14.9/34 | Optional 16.9/30
FUEL TANK: 270 litres
MAX ROAD SPEED: 40 km/h
UNLADEN WEIGHT: 7.0 tonnes
OVERALL WIDTH: 2.9m
OVERALL LENGTH: 7.67m
OVERALL HEIGHT: 3.6m
The Horizon 3000 has replaced the renowned Vision 3000 and carries on its ability to offer a high capacity machine at a relatively low overall weight. This allows it to tread lightly in damper conditions whilst still giving the performance required when spraying demands are at their highest.
Power is from the latest Deutz Tier 5 Final, 6-cylinder turbocharged engine driving through Poclain Boosted Braking wheel motors. These are now fitted with Dynamic and Boosted brakes on the front axle for improved stopping capabilities when travelling at higher road speeds.
All models benefit from a ‘load sensed’ hydraulic system which allows all operations to be carried out at low engine revs, reducing fuel usage and enabling swifter control of booms when spraying. It also allows a fast fill pump to be used in conjunction with the spray pump to give quicker filling whilst still being able to draw clean water through the induction hopper. Boom folding and unfolding is smooth and quick and enables booms to be folded in unison even on sloping ground.
‘Dual-ride’ suspension is a further development of our hydro-pneumatic system which offers the user a firm or soft ride. The firm setting is primarily for on road use to give a controlled feel at speed and softer when spraying in rough field conditions.
Booms up to 30m are available in either a rigid contour or our unique VG steel boom for boom levelling systems. Sands manufactured steel 2 fold boom sprays at 12, 24 and can be fitted with the latest Hypro ‘DuoReact’ Twin Line nozzle bodies for use with fertiliser dribble bars.
